Red Sawmill Laser Line, 50mw-200mw Edger, Headsaw


Kit Includes:

  • Red Laser Line Light
  • Laser Mount
  • Power Supply w/ Switch
  • Higher Watts mean you can see them farther away
No, I Want a Green Laser, Click Here
SKU: N/A Category: Tags: , , , , , ,


Red Line Laser Kit (650-660nm, 50mW/100mW/200mW) with AC Adapter and Flexible Mount – Water splash ok!

 1 Year Warranty

Red Laser Line Light 650 nm

Enhance your sawing with this high-precision red line laser module. Perfect for environments that are damp, this laser module is water resistant  design to perform reliably whether you’re outdoors or in a sawmill setting. The addition of an AC adapter makes it simple to get started right out of the box, and the precision glass lens ensures maximum beam accuracy and efficiency.

Complete Kit Ready to GO!

It generates a visible homogeneous distribution line with an aperture angle of 90°.  Which also means it stays a red consistent line from end to end.

This Kit Contains:

  1. Sawmill Laser Line, Red
  2. AC Adapter Power Supply, w/ switch
  3. Multi-position Mount.
  4. FREE Shipping (from factory ~ allow 2 weeks

Key Features:

  • Versatile Performance: Whether it’s cutting or precision alignment in construction, this laser module excels in various applications thanks to its water resistant build.
  • High Quality: Features a glass lens for superior light transmission and power resistance.
  • Fixed Focus: Set for a more crisp line at the board or log location!
  • Easy to Use: Comes with an AC-DC adapter & on and off switch for straightforward operation.


  • Wavelength: 650-660nm
  • Output Power: 50mW / 100mW / 200mW
  • Beam Divergence: 0.1-2mrad
  • Bend Rate: 1.5mm at 5 meters
  • Working Voltage: DC 5V
  • Laser Class: IIIb
  • Recommended Operating Temperature: 14°F to 95°F (-10°C to 35°C)
  • Duty Cycle: 4 hours on, 5 minutes off (longer when upgrade to a better mount or the Heat Sink)
  • Dimensions: 18mm x 100mm


Warning! These lasers emit radiation that can be harmful to the eye. Do not look directly into the laser aperture. Direct viewing of laser beam at close range may cause severe eye damage!!

Mounting Bracket

This multidirectional metal mounting bracket facilitates positioning and to provide additional heat sink protection to the laser diode module. Accommodates lasers 18mm” (18mm) in diameter.

Laser diode modules are positive to the case for optimal heat sinking. Do not mount metal brackets to the negative supply or negative earth without additional electrical isolation.

Overall Size: 4-7/8  x 3-1/2 x 1-1/4 (123.825 mm x 88.9 mm x 31.75 mm)

Power Supply

110-120VAC, power supply adapter, 5V DC Output for laser modules.

Specifications :
  •             Input :             110 -120VAC
  •             Output :          5V DC


Or give us a call: 1-888-806-8805

Additional information

Weight 2 lbs
Dimensions 6 × 4 × 4 in

50mW, 100mW, 200mW
